M&C TechGroup North America -
Gas Sampling and Gas Conditioning Technology
This is our portfolio of products tailor-made to meet the requirements of the North American market. To see the full catalogue of M&C Products, please refer to our global webpage at www.mc-techgroup.com.
Sorbent Trap System
The M&C Sorbent Trap Sampler system is designed to monitor total vapor-phase mercury (Hg) emissions in stationary source flue gas streams for Utility MACT (Maximum Achievable Control Technology standards) and MATS (Mercury and Air Toxics Standards) compliance for industries such as: power generation, cement, waste incinerators and several others required to install PS-12B (Appendix K) sorbent trap sampling systems in harsh, coal-fired environments on both dry and wet smoke stacks.
Smart Extractive System
The M&C Smart Extractive System is designed for any CEMS & process gas sampling for industries such as: Refineries, Chemical, Power Generation and several others requiring a reliable, clean and dry sample gas for analysis.
The microprocessor system offers server based remote viewing, troubleshooting and control (mimics local HMI) of parameters such as system status; probe, HSL, & chiller temperatures; validations; analyzer values and status.
Emails can be sent to alert the responsible personal of system critical alarms.
The Smart system can optionally include NIST traceable Mass Flow Controllers to blend Calibration/Validation gases on-demand.
Smart Dilution System
The M&C Smart Dilution System is designed to control all M&C dilution probes, and those by other manufactures. This unit controls all pneumatic, electric and communication routines associated with CEMS and process gas monitoring systems in hot, wet and high particulate environments for industries such as: Refineries, Chemical, Power Generation and several others requiring a reliable, clean and diluted sample gas for analysis.
The microprocessor system offers server based remote troubleshooting and control (mimics local HMI) of all parameters such as system status; probe, validations; analyzer values and status.
The Smart system can optionally include NIST traceable Mass Flow Controllers to blend Calibration/Validation gases on-demand.
CG-10 NO2 to NO Gas Converter
740-50A1205A
The CG-10 Gas Converter serves as a reliable plug and play instrument for converting NO2 molecules to NO for the sake of accurate and continuous NOx measurements. The CG-10 is commonly used in petrochemical applications, where the system designer can tie the converter into the purge system in order to meet hazardous atmosphere area class requirements.
NEW PRODUCT ANNOUCEMENT
Exclusive North American Distribution
Gas Eye Cross Duct in-situ analyzer
Having finished successful contract negotiations M&C has signed two far reaching
distribution contracts with the innovative company AIROPTIC of Poland.
AIROPTIC is a highly specialized company focusing on real-time gas analyzers.
It has developed and is producing laser based gas analyzers for industrial process control.
We will enhance our website shortly showing the additional sales program available
via M&C from now on.
The first contract is exclusively covering the sales region USA,
the second contract covers most of Europe (apart from Poland, Scandinavia and some
very special customers of AIROPTIC).
M&C will provide its own highly experienced sales force to introduce the technologically
smart products and solutions of AIROPTIC to all potential customers.
The technology of AIROPTIC
and the own developments of M&C will complement each other excellently and both partners
are proud and confident to be able to offer our customer industries new and highly qualified opportunities.
We are delighted to inform you about this new, future-orientated activity of M&C and can be reached through the existing contact channels as your exclusive AIROPTIC Sales Partner in the sales areas mentioned above.
The AIROPTIC Gas Eye is a maintenance free in-situ gas analyzer.
Designed for ambient, emission monitoring or process applications with 24/7 continuous operation.
There is no need for sample conditioning, does not exhibit zero or span drift, and no field calibration necessary. The Gas Eye can measure real time Formaldehyde, Ammonia, Carbon Monoxide and other gases that absorb in the mid IR region.
AIROPTIC’s Gas Eye is configured with a transmitter, process interface, and a receiver. The process interface is made of 316 stainless steel. The Interband Cascade Laser Technology allows measurement from ppb to ppm with large dynamic ranges, responding in less than 1 second.
The Gas Eye is easily adjustable to specific customer needs, ranging from ambient, to extractive through harsh combustion control environments. Windows for the Gas Eye are fused silica or sapphire (Helix leak tested and certified in accordance with EN1779:1999 norm), depending on the gas to be measured, and the application.
Industries Served
- Power
- Combustion
- Chemical
- Steel
- Food-Coffee Roasting
- Heat Treatment Operations
- Wood-based panel production
- Engineered Wood Products
- Painting & Corrosion Finishes
- Carpet Manufacturing & storage
- Adhesives
- Coatings & Varnishes
- Automotive Emissions
Gas Eye Features
- Process Temperatures up to 1200°C
- Real Time sensing with response times <1 second
- Formaldehyde detection limit < 10 ppb per meter
- Ammonia detection limit <0.1 ppm per meter
- Carbon Monoxide detection limit <0.2 ppm per meter
- No Interference from other gases in the sample
- Maintenance Free, no pumps, filters, moving parts
- Equipped with self calibrating feature, no field Cal. required
- Factory calibrated with certified span gas or NIST traceable gas
- Able to operate with up to 50g/m3 dust/particulates
- IP65 enclosure, suitable for outdoor/indoor & harsh environments
- ATEX version available
For further Information contact M&C TechGroup
